Gamber Johnson Panasonic FZ-G1/G2 Lite Port Replication Dock w No RF 7160-0487-20

Gamber Johnson Dock 7160-0487-20

Providing lite port replication, the Gamber Johnson 7160-0487-20 dock is a great piece of equipment for mounting a Panasonic TOUGHBOOK FZ-G2 or Toughpad FZ-G1. The 7160-0487-20 features an ethernet and serial port as well as 2 USB 3.0 ports but does not have an HDMI port or RF pass through (if an HDMI port or Dual RF is required please consider a full port replication dock such as Gamber Johnson part number 7160-0487-02). The dock can easily mount the FZ-G1 or FZ-G2 (without the keyboard) in a vehicle and has a VESA 75 mm mounting pattern making it compatible with most motion attachments. If you have any questions about the 7160-0487-20 or are interested in a quote for a complete in-vehicle computer solution including the FZ-G2 itself, give our sales team a call at 816-388-0035

7160-0487-20 Features

• Compatible with the Panasonic Toughpad FZ-G1 and TOUGHBOOK FZ-G2 tablet computers with small or large bumper guards
• Panasonic certified electronics
• Docking station accommodates the tablet's extended battery, smart card reader, rear hand strap and large bumper guards.
• Access to all tablet control buttons and ports while tablet is docked
• Easy docking and release, Insert computer into the docking station, push top of dock down and engage lock to dock computer
• Upward-facing I/O ports, integrated cable strain relief and cable management system Keyed lock for theft deterrence
• VESA 75mm mounting pattern
• Rounded edges to enhance personal safety
• Gamber-Johnson rugged construction and reliability
• Composite design for reduced weight and durability

7160-0487-20 Specifications

Weight

2.5 lbs / 1.13 kg

Height

9.14 in / 23.22 cm

Width

11.22 in / 28.5 cm

Depth

3.8 in / 9.65 cm

Port Replicators:

Panasonic certified electronics
(1) Ethernet - RJ45
(1) Serial - D-sub 9-pin
(2) USB 3.0 (900mA) - 9 pin
Power input - 16VDC
Antenna Switch

Antenna Pass-through:

No RF

Power Supply:

Power adapter is not included, please use one of the following:

LIND 11-16V Auto Power Adapter with Cigarette Lighter connector (7300-0459)
LIND 11-16V Auto Power Adapter with Bare Wire Lead (7300-0460)
LIND 12-32V Material Handling Isolated Power Adapter (7300-0464)
LIND 20-60V Material Handling Isolated Power Adapter (7300-0465)
LIND 72-110V Material Handling Isolated Power Adapter (7300-0417)
