Gamber Johnson 6 In. Locking Slide Arm 7160-0500

Gamber Johnson Motion Attachment 7160-0500

The Gamber Johnson 7160-0500 is a versatile motion attachment that is great for small or medium sized vehicle cabins that need adjustable and ergonomic positioning for a computer mount. With two different points of rotation, tilt and extension, the 7160-0500 can position a mounted computer or tablet to exactly where the user requires it. With a VESA 75 mm, Gamber Johnson 2x4, NEC and AMPs patterns the 7160-0500 motion attachment is compatible with virtually any laptop or tablet dock or cradle. Mounting to a Gamber Johnson upper pole or a smiley face mounting pattern, the 7160-0500 is a vehicle mounting component that is easy to install and is a critical component of a full mounting solution.

7160-0500 Features

• The entire arm can rotate around 360° with locking points at every 15°
• To rotate the arm simply pull the front lever out, rotate to desired position and then release the lever
• Locking slide arm can slide up to 5.5" (13.97 cm) from the center of the pole
• Motion Attachment:
  • New Motion Attachment works with the follow hole patterns:
    • VESA 75mm
    • Gamber-Johnson 2x4
    • NEC
    • AMPS
  • Tilt capabilities:
    • 90° forward allows for tablets to be easily mounted
    • 26° aft movement
    • Riveted design allows for smoother tilt movement
  • Swivel capabilities: 360°
• Can be mounted directly to a flat surface or on any Upper Pole, Complete Pole, Center Pole, Low Profile Bracket or Smiley Face Pattern
• Heavy gauge steel construction for long-term durability
• Black powder coat finish for maximum corrosion resistance

7160-0500 Specifications

Weight

4.9 lbs. / 2.2 kg

Height

4.6 in / 11.7 cm

Width

7.2 in / 18.4 cm

Depth

9.4 in / 23.9 cm

Rotates:

Motion Attachment - 360°.
Entire arm - 360° can lock at every 15°.

Tilt:

Yes - up to 90° fore / 26° aft

Slide:

Yes - up to 5.5" fore/aft
