Gamber Johnson 25 Inch Universal Console 7160-0770

Gamber Johnson Console Box 7160-0770

Designed to mount to either of the Gamber Johnson MCS top plates (long top plate 7160-0085 or short top plate 7160-0086) the 7160-0770 Universal Console can accommodate a number of different accessories (sold separately) such as armrests, cupholders, computer mounts, storage pockets and more. While the 7160-0770 is considered a universal console solution, the MCS top plates are typically mounted on vehicle specific leg kits and the 7160-0770 is limited by the mounting space available. Rugged or Die sales reps can help with any questions about the 7160-0770 or create a custom quote, email your requirements to sales@ruggedordie.com and we will respond within 1 business day.

7160-0770 Features

• 24.5" (62.2 cm) of straight mounting space plus 0.5" of overlap space to allow faceplates to fit flush
• Designed to house full sized devices and accessories
• Height adjustable with no side gaps in the console, ranges from 8.36" to 11.36" (21.2 cm - 28.9 cm)
• Angle adjustable at any height, ranges from 0° to 9°
• Adjustable support bracket in the center to strengthen the console box, along with fixed gussets in the bottom
• Can accommodate a power distribution block or Lind shut-down timer on the Front Plate
• Can accommodate most console box accessories including armrests, exterior cup holder, side pocket, DS-138, etc.
• Side pole mount (DS-138, sold separately) is angle adjustable to keep the pole vertical
• Rear armrest can be angle adjusted be using spacers on the bottom two bolts
• Three mounting locations on the side of the box for a mic clip or Adjustable Mic Clip (Item No. 7160-0826)
• Six 12V knockout panels for cigarette adapters
• Fully welded construction for long term product life span
• Box will ship fully assembled (except for accessories)
• 3 faceplates and 3 filler panels are included

7160-0770 Specifications

Weight

22.5 lbs. / 10.2 kg

Height

8.36" - 11.36" / 21.2 cm - 28.9 cm

Width

8.75" / 22.2 cm

Depth

25.0" / 63.5 cm

Placement:
