Gamber Johnson Low Profile Quick Release Keyboard Tray 7160-0857

Gamber Johnson Keyboard Mount 7160-0857

The Gamber Johnson 7160-0857 Low Profile Quick Release Keyboard Tray gives the user the ability to quickly dock and undock a keyboard on a vehicle equipment mounting solution. Splitting into two plates, the first plate of the 7160-0857 features a VESA 75mm mounting pattern and attaches to any motion attachment with the same hole pattern, the second plate features a number of AMPs hole patterns and attaches to the keyboard itself. Once the two plates are installed on the keyboard and motion attachment, a locking push button latch bridges them together for a secure mounting solution. With a keyed lock, the latch helps protect the keyboard from theft while simultaneously allowing for quick access and removal when needed. If you need help with integrating the 7160-0857 with a keyboard, give us a call at 816-388-0035 and the Rugged or Die sales team would be happy to assist!

7160-0857 Features

• Keyboard tray features a "stationary mounting plate" that is mounted permanently to the mounting system and a "mobile" plate used to mount the keyboard
• Stationary mounting plate has VESA 75mm hole pattern for easily attaching to any Gamber-Johnson motion attachment.
• Mobile plate offers a series of AMPS hole patterns offering additional versatility with your keyboard positioning allowing it to be offset either towards the driver or passenger for optimal ergonomics.
• Easy attachment by aligning the front side of the trays and securing by applying light pressure until you hear the latch click.
• Push button latch for easy keyboard release. Can be comfortably placed on the operator's lap for typing.
• Key lock for theft deterrent.
• Constructed of light weight yet durable composite material.
• Dual locks are provided for keyboards without AMPS hole pattern.
• Can be used with tablet display mounts.

7160-0857 Specifications

Weight

Weight: 2.30 lbs / 1.04 kg

Height

Height: 1.23" / 3.12 cm

Width

Width: 5.80" / 14.73 cm

Depth

Depth: 7.25" / 18.42 cm
