Gamber Johnson Wide Body Console 7160-0894

Gamber Johnson Console Box 7160-0894

The Gamber Johnson 7160-0894 Console Box is a wide bodied solution with a longer horizontal storage portion and is designed to maximize the horizontal mounting space between driver and passenger seats. While leg kits are typically vehicle specific, if a leg kit and tunnel plate can be installed in the vehicle the 7160-0894 should be compatible provided the vehicle has the proper mounting space. The console box provides angled and mounting spaces for accessories or equipment such as radios or siren controls and includes pre-drilled mounting locations for a computer dock motion attachment. While the 7160-0894 console box is considered a universal solution, many mounting locations in vehicles are asymmetrical and should be measured thoroughly to ensure compatibility, send an email with your requirements or questions to sales@ruggedordie.com and our sales team can help ensure you are getting the optimal equipment for your in-vehicle workstation!

7160-0894 Features

• Low profile, universal console with sloped front mounting area.
• Designed to work with top plate / tunnel plate and leg kits.
• Two 12 volt plug knock-outs, located on passenger side wall of console box and one knock-out for switches, dual USB power ports, battery. Voltage display, data / mic jack or USB / AUX input module extension
• PEMss for mounting mic clip (item no.7120-0723) on both sides.
• Side vented openings for air flow or mounting a speaker inside the console box.
• PEMs on back of console box for mounting an external cup holder (item no. 7160-0847) and armrest (item no. 7160-0429) or printer armrest (item no. 7160-0430).
• Front plate of console (underneath dash area) has placement for a power distribution block or Lind shut‐down timer using pre‐configured mounted holes.
• Computer can be center mounted either off‐set towards the passenger on the “smiley face pattern” or on the 3‐bolt pattern closer to the driver for easy articulation access.
• Fully welded construction for long term product life span.
• Comes with 3 faceplates and 3 filler panels.
• Box ships fully assembled (except for accessories).

7160-0894 Specifications

Weight

26.35 lbs. / 11.95 kg

Height

10.88" / 27.64 cm

Width

11.83" / 30.05 cm

Depth

24.75" / 62.87 cm

Mounting Space:

Horizontal, low profile section:

• Has a mounting area of 11.5" (29.2 cm) long to hold 11.5" of devices.
• Designed to house full-sized devices and accessories.
• Has additional side mounting area of 2" (5.1 cm) that will accommodate the 2-inch wide and 1.5-inch deep pocket (item no. 7160-0924), 2-inch faceplate for switches, power ports or a smaller device.

Vertical, angled sections:

• Accommodates 1 to 2 full-sized devices or faceplates (5" / 12.7 cm of mounting space)
• Two 12 volt plug knock-outs, located on top of the passenger side and 2 knockouts for switches, dual USB power ports, battery voltage display, data/mic jack or USB/AUX input module extension
