Gamber Johnson Mongoose 9 in. Locking Slide Arm w Short Clevis 7160-0928

Gamber Johnson Motion Attachment 7160-0928

Part of the industry defining Mongoose motion attachment family, the 7160-0928 9 inch Locking Slide Arm with Short Clevis provides robust articulation and motion options for a mounted rugged computer or tablet. Gamber Johnson designed the mongoose motion attachment to allow for computer tilt, rotation and extension and when mounted on a smiley face pattern the 7160-0928 can add additional rotation to the entire computer mount. The 7160-0928 can be mounted on a Gamber Johnson console or pedestal system. If you need a quote for the 7160-0928, the entire mounting solution or even the rugged computer, the Rugged or Die sales team can help! Give us a call at 816-388-0035

7160-0928 Features

• Designed is protected by US Patent Number 8,511,629
• Entire motion device capable of rotating 360 degree with locking every 15°
• Tilt Capabilities: 45° forward
• Swivel Capabilities: 360°
• The entire arm can rotate around 360° with locking points at every 15°
• To rotate the arm simply pull the front lever out, rotate to desired position and then release the lever Locking slide arm can telescope 9" to 13" from the center of the pole and utilizes the industry first "slam and lock" technology that allows you to simply push the computer back to the retracted position and it automatically locks into place
• Heavy duty, spring loaded steel, side pin was tested to 50,000+ cycles
• Can be mounted directly to a flat surface or on any Upper Pole, Center Pole, Low Profile Bracket, GJ console box via Smiley Face or 3-Bolt Hole pattern
• Two threaded inserts added to the back of the Mongoose to attach the Tablet Display Mount (Item No. 7160-0494 or 7160-0529)
• Heavy gauge steel construction for long-term durability
• Black powder coat finish for maximum corrosion resistance

7160-0928 Specifications

Weight

6.8 lbs. (3.08 kg)

Height

3.9" (9.9 cm)

Width

7.2" (18.4 cm)

Depth

11.3" (28.8 cm)
