Gamber Johnson Samsung Galaxy Tab Active2/3/5 Dual USB Dock w/ Bare Wire 7160-1368-00

Gamber Johnson Dock 7160-1368-00

Gamber Johnson docking station designed for Samsung Galaxy Tab Active2/3/5 with Dual USB and Bare Wire power adapter. When wired to your vehicle; the station provides power to your tablet’s battery so it will stay charged and ready to go.

7160-1368-00 Features

• Designed for the Samsung Galaxy Tab Active2 and Tab Active3 rugged tablet with rugged case
• Dual powered USB ports; 1.5A for each port for connecting peripheral devices
• Access to all control buttons, camera, ports and stylus while the tablet is safely docked
• Simple, one-handed cradle operation:
  • Insert bottom of Samsung tablet into the docking station and push top of the tablet in until the lock engages
  • Push latch button up with your thumb then remove the tablet from the docking station
• POGO pin connector and internal power supply provides power to charge the Samsung tablet while docked
• Push-button lock with key for theft deterrence
• VESA 75mm and AMPS mounting patterns; compatible with Zirkona mounting products
• Approximately 40” (101.6 cm) power cable with bare wire end
• Can be mounted on a flat vertical surface
• Composite design for reduced overall weight
• 10-40V power input range to support a wide range of mobile applications

7160-1368-00 Specifications

Weight

1.1 lbs / 0.5 kg

Height

6.7 in / 17.1 cm

Width

9.3 in / 23.6 cm

Depth

1.5 in / 3.8 cm

Port Replicators:

Tab Active2 - (2) USB 1.1 (1.5A each)
Tab Active3 - (2) USB 2.0 (1.5A each)

Antenna Pass-through:

No RF

Note: Disconnect software may affect compatibility on docks manufactured prior to 01/01/2024.
