Gamber Johnson TOUGHBOOK A3 Tablet Dock (NO RF) 7160-1416-00

Gamber Johnson Dock 7160-1416-00

The Gamber Johnson 7160-1416-00 dock is designed to be compatible with the FZ-A3 Panasonic TOUGHBOOK. The 7160-1416-00 docking station accommodates the tablet’s optional hand strap or extended battery. Port replication on the 7160-1416-00 includes dual powered USBs, an ethernet port, power input and an external antenna switch to control the use of an external antenna option. The 7160-1416-00 dock does NOT include RF pass through for external antennas, if that feature is needed please consider the alternative dock: Gamber Johnson part number 7160-1416-02. If you would like a custom quote for a complete mounting solution for the 7160-1416-00 and the FZ-A3, please email your requirements to the Rugged or Die sales department at sales@ruggedordie.com and we will respond within 1 business day! Rugged or Die is also pleased to offer the entire Panasonic TOUGHBOOK line of computers and accessories, if you have any TOUGHBOOK computer or related equipment needs we will happily provide a quote!

7160-1416-00 Features

• Compatible with the Panasonic TOUGHBOOK FZ-A3 tablet computer
• Panasonic Certified electronics
• Docking station design accommodates the FZ-A3 tablet hand strap with the extended battery
• Easy to use one-handed operation:

                -Insert bottom of computer into the docking station, push top of computer against latch button until latch engages

                -To remove, push up on latch-button with thumb to disengage and pull computer out of the docking station

• Access to all tablet control buttons and ports while tablet is docked
• Downward-facing I/O ports, integrated cable strain relief and cable management system
• Keyed lock for theft deterrence
• VESA 75mm mounting pattern
• Rounded edges to enhance personal safety
• Available with DUAL RF (Item No. 7160-1416-02)

7160-1416-00 Specifications

Weight

2.15 lbs / 0.98 kg

Height

10.28 in / 26.11 cm

Width

11.33 in / 28.78 cm

Depth

4.59 in / 11.66 cm

Port Replicators:

External Antenna Switch
Power Input
Ethernet (1)
Fully powered USB 2.0 (2) (1.0A)

Antenna Pass-through:

No RF

Power Supply:

Not Included - Use LIND 90W auto power adapter (Item No. 7300-0460)
