Gamber Johnson Zebra ET51/56 8 in. SLIM Dual USB Dock w/ MP205 Connection 7160-1506-02

Gamber Johnson Dock 7160-1506-02

Zebra ET51/56 8 inch SLIM Dual USB Docking Station with MP205 Connection. Docking station provides dual powered (1.5A each) USB ports; strong enough to connect a long-range scanner and other peripherals. Easily connect this docking station to an external power adapter using the MP205 connector on the power cable.

7160-1506-02 Features

• Designed for the Zebra ET51/56 8" rugged tablet computer with rugged frame
• This docking station does not accommodate ET51/56 accessories Front camera on ET5X accessible when the tablet is in the docking station
• Compatible with Windows or Android operating systems
• POGO pin connector and internal powered PCB provides power to charge the Zebra tablet while docked
• 8-40V power input range with power filtering PCB
• Dual powered USB ports; 1.5A for each port to connect peripheral devices
• Access to all control buttons and ports while the tablet is safely docked
• Bottom-facing I/O ports; integrated cable restraint/cable management system
• 40" power cable with MP205 in-line jack to quickly connect to a compatible power adapter
• Composite/aluminum design for reduced weight and extended durability
• Designed with rounded edges to enhance personal safety
• Keyed lock for security and theft deterrence
• Forward facing docking latch/release for easy one-handed operation: Insert bottom of Zebra tablet into the docking station and push top of the tablet until the lock engages To remove; lift latch to disengage and pull computer out of docking station
• VESA 75 mm and AMPS mounting patterns; compatible with Gamber-Johnson's Zirkona mounting products

7160-1506-02 Specifications

Port Replicators:

(2) Powered USB 2.0 (1.5A each)

Power Supply:

Internal powered PCB with 8-40V power input range provides power to charge the Zebra tablet while docked. Optional available external power adapters with MP205 connectors include: LIND 12-32V isolated material handling power adapter with MP205 connector (7300-0447) LIND 20-60V isolated material handling power adapter with MP205 connector (7300-0473) LIND 70-110V isolated material handling power adapter with MP205 connector (7300-0448)
