Gamber Johnson Zebra ET51/56 8 in. SLIM Cradle 7160-1506-90
Gamber Johnson Cradle 7160-1506-90
The Gamber Johnson 7160-1506-90 cradle is built for the Zebra ET51 and ET56 8 inch tablet line and this slim cradle design is perfect for a low profile tablet mounting solution. The 7160-1506-90 doesn't include any electronics or port replication but a power adapter (sold separately) can connect directly to the Zebra tablet while still docked. Featuring a locking latch, the 7160-1506-90 deters theft while maintaining ease of use with one handed operation of the latching mechanism. If port replication or power pass through is required for the Zebra tablet please alternatively consider a dock for the unit such as the Gamber Johnson part number 7170-0523. The 7160-1506-90 cradle or any other Gamber Johnson piece of equipment can be purchased directly on ruggedordie.com or email us for a free quote at sales@ruggedordie.com
7160-1506-90 Features
- Designed for the Zebra ET51/56 8" rugged tablet computer with rugged frame installed
- This cradle does not accommodate ET51/56 accessories
- Front camera on ET5X accessible when the tablet is in the cradle
- Compatible with Windows or Android operating systems
- Access to all control buttons and ports while the tablet is safely docked
- Composite/aluminum design for reduced weight and extended durability
- Designed with rounded edges to enhance personal safety
- Keyed lock for security and theft deterrence
- Forward facing docking latch/release for easy one-handed operation:
- Insert bottom of Zebra tablet into the cradle and push top of the tablet until the lock engages
- To remove, lift latch to disengage and pull computer out of cradle
- VESA 75 mm and AMPS mounting patterns; compatible with Gamber-Johnson’s Zirkona mounting products
Kit Includes:
- Zebra ET51/56 8" SLIM Tablet Cradle
- Mounting hardware
- Installation guide
7160-1506-90 Specifications
Weight
1.5 lbs / 0.68 kg
Height
8.75 in / 22.23 cm
Width
9.93 in / 25.22 cm
Depth
3.12 in / 7.92 cm
Power Supply:
NOT included. Use power supplies:
- LIND 11-16V Auto power adapter (7300-0415)
- LIND 12-32V Isolated Power Adapter (7300-0466)
- LIND 20-60V Isolated Power Adapter (7300-0467)
- LIND 72-110V Isolated Power Adapter (7300-0418)
Testing Specifications:
- MIL-STD 810G Shock/Vibration Tested
- MIL-STD 810G Environmental Testing: Humidity, High/Low Temperature, (storage/operational)
- SAE J1455 Crash Tested
- Cycle Tested: 30K Cycles, Docking Connector, Latching & Locking Mechanisms
- RoHS, FCC, CE Certifications
Port Replicators:
- None
Antenna Pass-through:
- No RF
Compatibility:
- Compatible with Zebra ET51/56 rugged tablet computer with rugged frame installed
