Gamber Johnson Getac F110 Vehicle Cradle (Tri RF) 7160-1642-03
Gamber Johnson Cradle 7160-1642-03
Designed specifically for the Getac F110 rugged tablet Gamber Johnson Vehicle Cradle 7160-1642-03 doesn't include any power or port pass through but does feature Tri RF pass through. With Tri RF pass through, a user can install external antennas that would attach to the 7160-1642-03 dock and boost the signal of the mounted Getac F110 (signals such as 4G LTE or GPS.) Though the 7160-1642-03 does not include any port replication, the cradle includes a keyed lock for anti-theft security. If port replication is a necessary feature, please alternatively consider the Gamber Johnson F110 dock 7170-0902-03. The vehicle mounting and docking experts at Rugged or Die can help you assemble the 7160-1642-03 into a full vehicle mounting solution for your F110, call us today at 816-388-0035 or send us an email with your requirements at sales@ruggedordie.com
7160-1642-03 Features
- Compatible with the Getac F110 G7 tablet and all previous versions of the F110 tablet
- Cradle accommodates the tablet's mag strip reader and rotating hand strap
- Access to all tablet control buttons and ports while the tablet is cradled
- One-hand docking and release for efficient use all day long
- Keyed lock for theft deterrence
- Gamber-Johnson rugged construction and reliability
- Composite design for reduced weight and durability
- VESA 75mm mounting pattern
Kit Includes:
- Getac F110 Vehicle Cradle
- Mounting Hardware
- Installation Instructions
7160-1642-03 Specifications
Weight
2.58 lbs / 1.17 kg
Height
13.33 in / 33.86 cm
Width
11.75 in / 29.85 cm
Depth
4.69 in / 11.91 cm
Power Supply:
Power adapter is not included, please use one of the following:
- Getac 120W automotive power adapter with bare wire lead (7300-0516)
- Getac 120W automotive power adapter with cigarette lighter connector (7300-0471)
- LIND 12-32V material handling isolated power adapter (7300-0413)
- LIND 20-60V material handling isolated power adapter (7300-0412)
- LIND 72-110V material handling isolated power adapter (7300-0416)
- NOTE: With the tablet in the cradle; the power adapter will plug directly into the tablet computer.
Testing Specifications:
- Getac Certified
- RoHS, FCC, CE, UKCA
- MIL-STD 810H vibration testing: Operational/Non-operational
- Shock crash hazard: SAE J1455, Mechanical Shock 40g
- Environmental: Thermal Shock, Humidity, High/Low Temperature - Storage/Operational
- Cycle Testing: Docking Connector, Latch and Locking mechanism - 30,000 cycles
Antenna Pass-through:
- Tri RF
