Gamber Johnson Panasonic TOUGHBOOK FZ-40 Cradle 7160-1729-00

Gamber Johnson Cradle 7160-1729-00

Built specifically for the Panasonic TOUGHBOOK FZ-40, the Gamber Johnson 7160-1729-00 Cradle is crafted out of quality materials and composite, providing durability as well as reduced weight. Designed to match the footprint of the FZ-40 TOUGHBOOK, the 7160-1729-00 preserves valuable cabin space in the vehicle. With a keyed latch for locking, the 7160-1729-00 provides theft deterrence when the computer is left unattended. The cradle is meant only to secure the FZ-40 in the vehicle safely and does not provide any power or port replication. If you require these features, please consider an FZ-40 vehicle dock such as Gamber Johnson part number 7160-1728-07. Though the 7160-1729-00 cradle doesn't provide any port replication, the operator will have full access to all ports on the FZ-40 while the computer is docked. If you need help completing the mounting solution for your Panasonic TOUGHBOOK FZ-40 or if you are in the market for the FZ-40 laptop itself, Rugged or Die is pleased to offer the entire Gamber Johnson and Panasonic TOUGHBOOK catalog, call us at 816-388-3005 for a free consultation and quote!

7160-1729-00 Features

  • Access to all computer control buttons and most ports while docked
  • Designed to the footprint of the computer to preserve cabin space
  • Right-facing docking/release latch for easy docking and undocking
  • Keyed lock for theft deterrence
  • Gamber-Johnson rugged construction and reliability
  • Composite design for reduced weight and durability
  • VESA 75mm mounting pattern for compatibility with a variety of Gamber-Johnson motion attachments

Kit Includes:

  • Panasonic TOUGHBOOK 40 Cradle (No electronics) (7160-1729-00)
  • Mounting Hardware
  • Installation Instructions

7160-1729-00 Specifications

Weight

4.5 lbs / 2.04 kg

Height

2.8 in / 7.11 cm

Width

14.65 in / 37.21 cm

Depth

12.31 in / 31.27 cm

Warranty:

  • 3-year Limited Lifetime Warranty
  • Extended Warranty/Gamber Guard Options Available

Power Supply:

Power adapter is not included, please use one of the following:

  • LIND 11-16VDC Auto Power Adapter with LED light and cigarette lighter connector (7300-0216)
  • LIND 11-16VDC Auto Power Adapter with bare wire lead (7300-0461)
  • LIND 11-16VDC Auto Power Adapter with cigarette lighter connector (7300-0462)

Antenna Pass-through:

  • No RF

Model Compatibility:

  • Panasonic TOUGHBOOK FZ-40
$510.09 USD
$510.09 USD
Shipping calculated at checkout.
