Gamber Johnson Zirkona Outdoors Portable Live Sonar Shuttle 7160-1844

Gamber Johnson Accessory Mount 7160-1844

Compatible with a large number of sonars and fish finders, the Gamber Johnson Zirkona Outdoors Portable Live Sonar Shuttle 7160-1844 can increase the portability and utility of your fishing unit. Compatible with Garmin, Lowrance and Humminbird graphs up to 12 inches, the 7160-1844 includes 3/8 inch mounting holes for other Zirkona solutions such as a phone or GoPro holder. Interested in the 7160-1844 or other Zirkona outdoor accessories? Purchase directly online or consult with a Rugged or Die sales expert today on our live chat!

7160-1844 Features

• Sealed wooden handle is less thermo-conductive meaning easier handling, no matter the outdoor temperature.
• A 12 volt SAE charge port and pigtail can help adapt to different battery chargers (customer must supply correct terminals)
• Front panel has 3 screws that can be easily removed to gain access to the battery compartment - no need to disassemble the battery compartment from the larger shuttle frame.
• Ships fully assembled with wiring harness, cable hooks, and hardware unassembled inside the shuttle.
• 3/8" holes under each side of the handle for mounting Zirkona solutions for GoPro's and Phones to ensure your devices stay close.
• All black powder-coated aluminum shuttle for strength and protection from mother nature
• Works with Garmin, Lowrance, and Humminbird graphs up to 12" (some drilling may be required)
• Bring with you from boat to boat to dock; wherever you can use live sonar, you can take the shuttle
• Graph is mounted higher up making the unit easier to see and interact. (Must use factory gimbal bracket; not included with shuttle)
• For Garmin and Lowrance: sonar module is mounted up on the back of the shuttle via predetermined holes, keeping it out of dirt, ice, and snow.
• Handle can be grabbed conveniently with or without gloves, without hitting the transducer cable.
• Cable hooks included for convenient storage of the transducer cable.
• Battery compartment highlights:
  • Large compartment for different size batteries.
  • Adjustable strap to fit to your battery.
  • Battery mat to help battery stay in place and provide a thermal barrier from hot and cold environments.
• Front instrument panel features:
  • USB-A and USB-C inputs for powering external accessories
  • Voltage meter letting you know how much battery power is left AND what the current voltage is running from the battery.
  • Main Power Switch turns on/off the entire system (when following our wiring procedure)

7160-1844 Specifications

Weight

9 lbs / 4.08 kg

Height

18.06" / 45.87cm

Width

12.77" / 32.44cm

Depth

9.8" / 24.89cm

Device Compatibility:
