Gamber Johnson DeX Heads Up Vehicle Kit without Hub 7170-0757-02

Gamber Johnson Display 7170-0757-02

Gamber Johnson DeX heads up vehicle kit without hub. DeX vehicle kit includes a 13.3″ touch-screen display, keyboard and cradle, smartphone dock mounting bracket and articulating mount. Gamber-Johnson’s Heads Up DeX solution positions the smartphone in the driver’s view – use the phone as a second screen or a touchpad device.

7170-0757-02 Features

  • Add a compatible Heads Up Smartphone Docking Station (7160-1394-00 Note9), (7160-1394-01 S9+), (7160-1394-02 S9), (7160-1394-03 S10+), (7160-1394-04 S10), (7160-1394-05 Note10), (7160-1394-06 Note10+), (7160-1394-07 S10e) to complete your DeX vehicle solution. Must order Separately.
  • Smartphone requires a Rebel phone case to be compatible with the smartphone docking station; (18551-00 Note9), (18551-01 S9+), (18551-02 S9), (18551-03 S10+), (18551-04 S10), (18551-05 Note10), (18551-06 Note10+) and (18551-07 S10e). Must order Separately.
  • This DeX Heads Up vehicle solution positions the smartphone dock next to the touch screen where you can use your phone as a secondary screen or a touchpad device
  • Mount the 13.3" touch screen to a Gamber-Johnson close-to-dash mount (7160-1346 or 7160-0822) or tablet display mount (7160-0529 or 7160-0494) for optimal viewing
  • 13.3 inch 5-point capacitive touch screen, high resolution 1920 x 1080, Brightness: 50-1000 nits (adjustable)
  • Quick release keyboard cradle; remove keyboard to a different work surface and return to the keyboard mount when complete
  • Gamber-Johnson offers several DeX solutions including:
    • The DeX Armrest vehicle solution that positions the smartphone dock in the vehicle armrest next to the driver where it is out of the way but still accessible
    • The DeX Desktop solution that enable the mobile worker to transition from vehicle to desktop seamlessly
    • Contact Gamber-Johnson for more information about their DeX solution kits and DeX components and accessories

Kit Includes:

  • 13.3" Touch Screen Display - Includes power cable, HDMI cable, USB Type B cable (7160-1451-00)
  • Smartphone Dock Heads Up Articulating Mount (7110-1237)
  • Smartphone Dock Heads Up Mount Bracket (18540)
  • Installation Guides
  • Mounting Hardware

7170-0757-02 Specifications

Testing Specifications:

MIL-STD 810G Shock and Vibration Specifications
MIL-STD 810G Temperature and Humidity (operational and storage)
SAE J1455 30mph Crash Testing
Cycle Testing: Keyboard - 2 Million Actuations


Port Replicators:

13.3" Touchscreen Display (7160-1451-00)

(1) HDMI
(1) VGA
(1) USB type C (2A @ 5V) fast charging
(1) USB type B (for Touch Control)
(2) USB 3.0 (fast charging 1.5A)
(1) Aux. out 3.5 mm
(1) DC input (Barrel Jack)

Rugged Lite Keyboard (7160-1449-00)

(1) USB Type A

DIMENSIONS

  • 13.3" Touch Screen Display (7160-1451-00)
    • Weight: 6.65 lbs / 3.02 kg
    • Height: 9.94 in / 25.25 cm
    • Width: 13.75 in / 34.93 cm
    • Depth: 1.57 in / 3.99 cm
  • Quick Release Keyboard Cradle (7160-1470-00)
    • Weight: 0.55 lbs / 0.25 kg
    • Height: 1.01 in / 2.57 cm
    • Width: 5.5 in / 13.97 cm
    • Depth: 7.35 in / 18.67 cm
  • Rugged Lite Keyboard (7160-1449-00)
    • Weight: 1 lbs / 0.45 kg
    • Height: 0.68 in / 1.73 cm
    • Width: 10.31 in / 26.19 cm
    • Depth: 7.12 in / 18.08 cm
  • Heads Up Articulating Mount (7110-1237)
    • Weight: 0.2 lbs / 0.09 kg
    • Height: 2.75 in / 6.99 cm
    • Width: 2.12 in / 5.38 cm
    • Depth: 2.12 in / 5.38 cm
  • Heads Up Mounting Bracket (18540)
    • Weight: 0.74 lbs / 0.34 kg
    • Height: 0.5 in / 1.27 cm
    • Width: 12 in / 30.48 cm
    • Depth: 5.75 in / 14.61 cm
