Havis IP65 Tablet Dock for Dell Latitude 7230/7030 Rugged Extreme Tablet & Non-isolated, Internal Power Supply DS-TAB-302

Havis Dock DS-TAB-302

Havis IP65 Tablet Docking Station for Dell Latitude 7230/7030 Rugged Extreme Tablet and Non-isolated, Internal Power Supply Applications

DS-TAB-302 Features

• Supports Dell's Latitude 7230 & 7030 Rugged Extreme Tablets in Warehouse & Distribution, Energy & Utilities, Public Safety, and other demanding environments
• Docking station pairs with TA-100 series tablet adapter to provide IP65 rating while maintaining device mobility
• Havis-designed port replication to connect multiple mission-critical peripherals
• LED power indicator
• IP65 sealed I/O panel accomodates a variety of cable diameters
• One-handed docking & undocking
• Features an internal, non-isolated power supply (9-36V)
• Provides access to all buttons, ports, and bar code scanner both docked and undocked
• Compatible with Dell 7230 tablet accessories including hard and soft handles and shoulder strap
• Compact & lightweight
• Integrated cable management system
• Integrated VESA 75 mounting pattern
• Polycarbonate construction ensures strength, ruggedness and extreme temperature resistance
• Rounded edges and corners for comfort and safety
• Keyed lock under sealed cover for added security
• Made in USA

DS-TAB-302 Specifications

Compatible computer:    Dell Latitude 7230 & 7030 Rugged Extreme Tablets
Certifications:    Vibration Testing: MIL-STD 810H 514.8 Crash Testing: SAE J1455 30mph Cycle Testing: Latch handle and docking connectors 30K cycles Environmental Testing: Hot/Cold operational -29° C to 55° C for DOCK ONLY (-20° F to 131° F); Hot/Cold storage -40° C to 85° C (-40° F to 185° F); Ingress Protection Rating: IP-65
Port Replication:    (1) RJ45 Ethernet, (3) USB2.0 Type A, (1) DB9 Serial - 5V powered, (1) DC In port
Dimensions:    8.43" (21.41cm) W x 9.59" (24.36cm) H x 2.06" (5.23cm) D
Product weight:    2.10 lbs (0.953 kg)
Gross weight:    2.5 lbs
